Automatic Pick & Place Machines

Explore SMTmax automatic pick & place machines for PCB prototyping, small-batch assembly, and high-volume SMT production.

Shop Pick & Place Machines

Jump to comparison →
QM2040 Automatic Pick & Place MachineCompact

QM2040

Automatic Pick & Place Machine

Compact two-head system for prototyping, engineering labs and small-batch in-house SMT assembly.

2Placement Heads
40Feeder Capacity
12 × 9 inPCB Working Area
2,500–4,000 PPHEstimated Throughput
QM4044 Automatic Pick & Place MachinePopular

QM4044

Automatic Pick & Place Machine

Four-head stand-alone machine with more placement capacity, an internal conveyor and flexible feeder support.

4Placement Heads
44Feeder Capacity
13 × 10 inPCB Working Area
6,000–7,000 PPHEstimated Throughput
QM6064 Automatic Pick & Place MachineHigher Capacity

QM6064

Automatic Pick & Place Machine

Six-head production system with a larger PCB work area and higher feeder capacity for more demanding jobs.

6Placement Heads
64Feeder Capacity
500 × 370 mmPCB Working Area
9,000–10,000 PPHEstimated Throughput
QM8080 Automatic Pick & Place MachineHighest Throughput

QM8080

Automatic Pick & Place Machine

Eight-head production system with 80 feeder positions and the highest placement throughput in the current QM lineup.

8Placement Heads
80Feeder Capacity
500 × 380 mmPCB Working Area
11,000–12,000 PPHEstimated Throughput
Side-by-side

Compare Pick & Place Machine Specifications

SpecificationQM2040QM4044QM6064QM8080
Placement Heads2468
Feeder Capacity40446480
Maximum PCB Working Area12 × 9 in13 × 10 in500 × 370 mm500 × 380 mm
Estimated Placement Speed (PPH)2,500–4,000 PPH6,000–7,000 PPH9,000–10,000 PPH11,000–12,000 PPH
Electrical Requirements110V AC / 60 Hz or 220V AC / 50 Hz110V AC / 60 Hz or 220V AC / 50 Hz110V or 220V AC, 50/60 Hz110V / 220V
Best Suited ForPrototyping & small productionGrowing in-house productionLarger boards & higher throughputHighest lineup throughput

Need Help Choosing a Pick & Place Machine?

Send us your PCB dimensions, bill of materials (BOM), and production requirements. Our team can help you select the right machine and feeder configuration.

Ask Our Team →
